詳細情報 |
|||
| 色: | グレー、カッパー、シルバー | 材料: | 導電性フォーム、布、アルミ箔、銅箔 |
|---|---|---|---|
| 巻き込む: | プラスチック、ゴム、金属 | に適しています: | HPプリンター、モニターカメラ、イヤホン、リモコン |
| テープ: | 導電性も | 消火剤: | UL94 HBおよびUL94 V0 |
製品の説明
Electrically conductive fabric used for electromagnetic shielding, EMI/EMC.
Conductive foam and sheet include electrically conductive PU foam and fabric, aluminum foil, copper foil, silicon and so on.
This is the data sheet sample of 50μmm double conductive AL foil:
| No. | item | unit | spec | standard | test method |
| 1 | thickness | u | 50u | 50u±3 | |
| composition | ％ | 99.9↑ | 99.9↑ | ||
| 2 | glue thickness | u | 40 | 40±5 | ASTM-1000 |
| composition | — | conductive glue | conductive glue | ||
| 3 | total thickness(1+2) | u | 90U | 90U ±8 | |
| 4 | adhesion to copper board | kg/in | 0.8↑ | 0.8↑ | ASTM-1000 |
| 5 | first adhesion(#10) | kg/in | 1↑ | 1↑ | J.DOW |
| 6 | endurance adhesion | Hours | 12↑ | 12↑ | ASTM.D-3654 |
| 7 | resistivity | ¤ | 0.06 | ≤0.08 | PURPILLARS |
| 8 | weatherability | ℃ | 90-120℃ | 90-120℃ | |
| 9 | test environment | 23℃,65% relative humidity. | |||
| 10 | storage condition | temperature:(25±5)℃RH:(50±30)% | |||
この製品の詳細を知りたい
